FRONT WING R-FOIL HIGH

Front wing foil wing Reptile

Front wing foil wing Reptile

Our High Aspect foil dedicated to freeride, wave riding and freestyle. Speed and performance within everyone's reach.

Model Size
  • 1300
  • 2000
23HIFW13
€323.77

Product Details

Material
Carbon 80%
Model
R-FOIL HIGH 1300
R-FOIL HIGH 2000
Included accessories
Front Wing
Screws set
Skill level
Advanced
Intermediate
Program
Allround
Fun

Description

Front wing foil wing Reptile

The R-Foil High is our High Aspect foil dedicated to freeride, wave riding and freestyle. Speed and performance within everyone's reach.
The R-Foil High program includes two foils in the "High aspect" category designed exclusively for speed and high performance, without obviously negatively affecting stability and lift. It is the result of a whole year of work, research and testing. This foil consolidates everything we were looking for: early lifting, speed and ease of use. It is ideal for wing foiling, sup / surf and downwind.
We have confirmed the extra-rigid aluminum mast, now also available in the 90 cm version, and the R-Foil fuselage that resists the pressure given by the wings during transitions and jumps. The new R-FOIL HIGH full carbon front wing is able to combine performance and accessibility for all levels of riders.
While the R-Foil 2000 is best for super light wind and heavy riders, the R-FOIL HIGH 1300 is simply a step up in performance. With this foil set you get more speed to allow you to push your level further. Glide faster, apply more pressure and draw sharper curves even with smaller surfs. For wing foiling it is ideal for a more consistent wind range, but still has an exceptionally early takeoff for riders who have good pumping technique. Combined with the new 45 rear wing, this setup allows you to accelerate and jump high. Excellent for experienced freestylers and extremely fun for surfing the waves. For surf foiling it is fast and super responsive for small to medium waves.

IMMAGINI ACTION

high-reptile-wing-foil
wingfoil-perfect-reptile
reptile-perfect-foil-fast-easy
reptile-foil-fast-fourious
hydrofoil-easy-fast-jump-reptile
foil-reptile-fast

MODEL

1300

2000

FRONT

94x18,6 cm

105x24,5 cm

AR

6,7

5,7

PESO

1,4 KG

1,9 KG

SHAPE AND TECHNICAL CHARACTERISTICS

R-FOIL HIGH 2000
The largest model. It has a 105cm wingspan and a 24.5cm rope. The Aspect Ratio of 5.7. This foil has huge lift, and is perfect for light wind freeriding and pumping. Its infinite glide and agility make it excellent both in flat water and on small waves, where its great thrust combined with its limited thickness make it accelerate and turn in an easy and decisive way.


THE SET INCLUDES:
• Mast Plate
• 90 cm Mast
• Fuselage
• R-FOIL front wing High 2000
• Stabilizer 48 x8.5 cm
• Set of screws (4 x base plate, 3 x front wing, 2 x stabilizer, 2 x mast / fuselage connection)
• Foil bag

R-FOIL HIGH 1300
The smallest model, with a 94cm wingspan and 18.6cm rope. Although the front wing has an area of 1300 cm2, with its Aspect Ratio of 6.7 this foil is incredibly stable and is the perfect choice for those who want to get off the 2000 model and go considerably faster without losing any control. We have kept the same stabilizer in order to make the R-Foil 1300 High usable by all. With its maximum thickness of 17.5mm, the R-Foil High 1300 is amazing in takeoff and in the average and top speed it can achieve. Furthermore, thanks to its 72 cm fuselage, the foil remains stable even under the feet of the less experienced. Huge upwind, downwind and pumping capabilities, it's the foil of choice for anyone who likes to freestyle on the plate or in the waves. Feeling, it seems to have a bigger foil in terms of stability, and smaller in terms of speed and agility in cornering. Unbeatable

THE SET INCLUDES:
• Mast Plate
• 90 cm Mast
• Fuselage
• R-FOIL front wing High 1300
• Stabilizer 48 x8.5 cm
• Set of screws (4 x base plate, 3 x front wing, 2 x stabilizer, 2 x mast / fuselage connection)
• Foil bag

THE PRODUCTION PROCESS

The R-Foil High is made up of aluminum elements and carbon fiber elements.
The base plate, the mast and the fuselage are made of solid anodized aluminum which offer an unbeatable value for money.
The wings are instead made with an efficient mix of glass and carbon fibers, laminated and pressed at high pressure and temperature. Inside the wings there is a PVC core, which, combined with the glass and carbon fibers, gives the R-Foil High total rigidity.
The ends of the wings are rounded in order to minimize damage in the event of an accidental impact against the wing or feet. We wanted to put safety first. With the R-Foil High you will absolutely not be able to cut yourself.

MATERIALS, HOW IT'S MADE

• Anodized aluminum plate for US BOX connection
• Column in extruded anodized aluminum
• CNC machined aluminum fuselage
• Carbon front wing and rear stabilizer

FOR WHO, FOR WHAT, WHY REPTILE

FOR WHO?
R-Foil High is the perfect foil for advancing wing foil. The two sizes perfectly cover the range of use from 7 to 35 KN, and thanks to the stabilizer and its fuselage their use is easy for everyone. The beginner will appreciate the lift and moderate speed of the 2000, while the intermediate rider will be amazed by the speed and agility of the 1300.


FOR WHAT?
Freeride, wave, freestyle and why not, slalom. The R-Foil High are polyvalent foils, which can also be used with Sup, surfing and windsurfing.


WHY REPTILE?
We have twenty years of experience in the design and development of windsurf masts and accessories. We live, breathe, exude R&D and carbon fiber, we have celebrated countless world cup victories thanks to the performance but also the reliability of our products. Now the company is 70% oriented on wing foil design, that's why #ridereptile and #flyreptile.

FOIL MAINTENANCE

All the contact parts of the foil and the screws must be periodically disassembled and rinsed with fresh water. The salt can cause corrosion of the aluminum parts in contact with the carbon and steel of the screws.
We recommend using marine gels or grease to protect these parts from corrosion.

WARRANTY

What damage does the warranty cover?

Each Reptile Sports product is subjected to rigorous quality controls during every single production phase. Each product is carefully checked to ensure that the technical characteristics comply with the specifications. Non-compliant products are NOT placed on the market but destroyed.
The warranty covers manufacturing defects and / or material defects with a duration of twenty-four months (24) from the date of purchase, in the case of sale to the direct user.
 This date must be proven by a delivery document issued by the seller (e.g. receipt), in which the following appear: the delivery date, the name of the seller, the identification details of the same (type, model).
 Main defects in materials and workmanship
The defects of the materials, and in particular of the carbon composites, are normally highlighted in the initial use phase. If a product is faulty (and this can happen), it breaks down after a few exits. Breakages occurred after months of use, are hardly attributable to defects in material or production, but rather to shocks or stress following poorly executed maneuvers, impact with the seabed, whirled in the waves. This does not mean that the guarantee is not recognized, but that it may be necessary for us to carry out a greater analysis of the damaged parts to understand if the nature of the break occurred due to a defect or inexperience.
